Light-Emitting Diode (LED)
Light-Emitting Diode (LED)

ALL

Auto. SMD LED 3528 PLCC-2

LED Lamp Dip Type

SMD 0603/0805/1206/1615

Image Description and Main Parameters Part Series Code Dimension Original Part Number Documents
Automotive SMD LED with 60° lens PLCC-2 3528 VF: 2.7~3.3V. Luminous Flux Rank: 6.2~12.8Im. CCT: 5300~7000K. BDC series Cool White Color BDCECW000000S0 L3.50*W2.80*H1.85mm BDC-ECW-000000 Data Sheet View Inventory
Automotive SMD LED with 60° lens PLCC-2 3528 VF: 2.85~3.65V. DWL: 515~530nm. IV: 4500~7500mcd. BDC series Green Color BDCEG000000S00 L3.50*W2.80*H1.85mm BDC-EG-000000 Data Sheet View Inventory
Automotive SMD LED with 60° lens PLCC-2 3528 VF: 2.85~3.65V. DWL: 463~475nm. IV: 4500~7500mcd. BDC series Blue Color BDCEB000000S00 L3.50*W2.80*H1.85mm BDC-EB-000000 Data Sheet View Inventory
Automotive SMD LED with 60° lens PLCC-2 3528 VF: 1.9~2.65V. DWL: 584~596nm. IV: 5670~17800mcd. BDC series Yellow Color BDCEY000000S00 L3.50*W2.80*H1.85mm BDC-EY-000000 Data Sheet View Inventory
Automotive SMD LED with 30° lens PLCC-2 3528 VF: 2.75~3.5V. DWL: 500~510nm. IV: 3600~7580mcd. BDC series Bluish Green Color BDCDBG000000S0 L3.50*W2.80*H1.85mm BDC-DBG-000000 Data Sheet View Inventory
Automotive SMD LED with 30° lens PLCC-2 3528 VF: 1.8~2.4V. DWL: 620~628nm. IV: 2290~5740mcd. BDC series Red Color BDCDR000000S00 L3.50*W2.80*H1.85mm BDC-DR-000000 Data Sheet View Inventory
Automotive SMD LED with 30° lens PLCC-2 3528 VF: 1.8~2.4V. DWL: 584~596nm. IV: 2290~5740mcd. BDC series Yellow Color BDCDY000000S00 L3.50*W2.80*H1.85mm BDC-DY-000000 Data Sheet View Inventory
Automotive SMD LED with 60° lens PLCC-2 3528 VF: 1.8~2.4V. DWL: 618~628nm. IV: 1460~4580mcd. BDC series Red Color BDCER000000S00 L3.50*W2.80*H1.85mm BDC-ER-000000 Data Sheet View Inventory
Automotive SMD LED with 30° lens PLCC-2 3528 VF: 2.75~3.75V. DWL: 464~476nm. IV: 1170~3600mcd. BDC series Blue Color BDCDB000000S00 L3.50*W2.80*H1.85mm BDC-DB-000000 Data Sheet View Inventory
Automotive SMD LED PLCC-2 3528 VF: 1.9~2.5V. DWL: 584~596nm. IV: 450~1460mcd. BDB series Yellow Color BDBNY000000S00 L3.50*W2.80*H1.85mm BDB-NY-000000 Data Sheet View Inventory
Automotive SMD LED PLCC-2 3528 VF: 1.9~2.5V. DWL: 628~639nm. IV: 362~1170mcd. BDB series Super Red Color BDBNSR000000S0 L3.50*W2.80*H1.85mm BDB-NSR-000000 Data Sheet View Inventory
Automotive SMD LED PLCC-2 3528 VF:2.8~3.4V. WLD:495~510nm. IV 910~2290mcd. BDB series Cyan Color BDBNCA000000S0 L3.50*W2.80*H1.85mm BDB-NCA-000000 Data Sheet View Inventory
Automotive SMD LED PLCC-2 3528 VF:2.65~3.4V. CCT: 6500~7000K. IV 1170~3600mcd. BDB series Cool White Color BDBCW2MM000000 L3.50*W2.80*H1.85mm BDB-CW2MM-000000 Data Sheet View Inventory
Automotive SMD LED PLCC-2 3528 VF:1.9~2.1V. WLD: 620~628nm. IV 560~1890mcd. BDB series Red Color BDBNR000000S00 L3.50*W2.80*H1.85mm BDB-NR-000000 Data Sheet View Inventory
Automotive SMD LED PLCC-2 3528 VF:1.9~2.5V. WLD: 612~624nm. IV 710~2290mcd. BDB series Amber Color BDBNA000000S00 L3.50*W2.80*H1.85mm BDB-NA-000000 Data Sheet View Inventory
SMD LED Dice Red/Green/Blue Diffused, IV: 17.5/43.5/12mcd Min. VF: 1.6/2.5/2.5V Min. WLD: 620/515/464nm Min. BND16RGBAS0001 L1.60*W1.50*H0.60mm BND-16RGBA Data Sheet View Inventory
SMD LED Disc White Clear, IV: 182mcd Min. VF: 2.8V Min. CCT: 6201k Min. BND1206JKWS001 L3.20*W1.60*H0.90mm BND-1206JKW Data Sheet View Inventory
SMD LED Disc Red Clear, IV: 58mcd Min. VF: 1.8V Min. WLD: 620nm Min. BND1206JKRS001 L3.20*W1.60*H0.90mm BND-1206JKR Data Sheet View Inventory
SMD LED Disc Blue Clear, IV: 150mcd Min. VF: 2.75V Min. WLD: 460nm Min. BND1206JKBS001 L3.20*W1.60*H0.90mm BND-1206JKB Data Sheet View Inventory
SMD LED Disc Yellow Green, IV: 150mcd Min. VF: 1.8V Min. WLD: 567nm Min. BND0805JKYGS01 L2.00*W1.25*H0.85mm BND-0805JKYG Data Sheet View Inventory
SMD LED Disc Red Clear, IV: 58mcd Min. VF: 1.8V Min. WLD: 620nm Min. BND0805JKRS001 L2.0*W1.25*H0.85mm BND-0805JKR Data Sheet View Inventory
SMD LED Disc Pure Green, IV: 150mcd Min. VF: 2.4V Min. WLD: 515nm Min. BND0805JKGS001 L2.00*W1.25*H0.85mm BND-0805JKG Data Sheet View Inventory
SMD LED Disc Blue Clear, IV: 150mcd Min. VF: 2.75V Min. WLD: 460nm Min. BND0805JKBS001 L2.00*W1.25*H0.85mm BND-0805JKB Data Sheet View Inventory
SMD LED Disc Yellow Green, IV: 1.5mcd Min. VF: 1.8V Min. WLD: 567nm Min. BND0603JKYGS01 L2.0*W1.25*H0.8mm BND-0603JKYG Data Sheet View Inventory
SMD LED Disc Red Clear, IV: 150mcd Min. VF: 1.8V Min. WLD: 620nm Min. BND0603JKRS001 L2.0*W1.25*H0.8mm BND-0603JKR Data Sheet View Inventory
SMD LED Disc Pure Green, IV: 150mcd Min. VF: 2.4V Min. WLD: 515nm Min. BND0603JKGS001 L2.0*W1.25*H0.8mm BND-0603JKG Data Sheet View Inventory
SMD LED Disc Blue Clear, IV: 150mcd Min. VF: 2.75V Min. WLD: 460nm Min. BND0603JKBS001 L2.0*W1.25*H0.8mm BND-0603JKB Data Sheet View Inventory
RED LED LAMPS with Flange, 3MM Round RALLF3053A10B1 Φ3.0*5.3mm RALLF3053A10B1 Data Sheet View Inventory
YELLOW LED LAMPS with Flange, 3MM Round YLLLF3053A10B1 Φ3.0*5.3mm YLLLF3053A10B1 Data Sheet View Inventory
PURE GREEN LED LAMPS with Flange, 3MM Round PGLLF3053A10B1 Φ3.0*5.3mm PGLLF3053A10B1 Data Sheet View Inventory
SMD LED Dice Red/Green/Blue Diffused, IV: 80/210/94mcd Min. VF: 1.8/2.7/2.7V Min. WLD: 620/522/467nm Min. 1615RGBBD168S1 L1.60*W1.60*H0.60mm 1615RGB-BD-168 Data Sheet View Inventory
SMD LED Disc Blue Clear, IV: 95mcd Min. VF: 2.7V Min. WLD: 466nm Min. 1206BBD8100S01 L3.20*W1.60*H0.90mm 1206B-BD-810 Data Sheet View Inventory
SMD LED Disc Red Clear, IV: 115mcd Min. VF: 1.8V Min. WLD: 620nm Min. 0603RBD0700S01 L1.60*W0.80*H0.60mm 0603R-BD-070 Data Sheet View Inventory
SMD LED Disc Green Clear, IV: 275mcd Min. VF: 2.6V Min. WLD: 520nm Min. 0603GBD0790S01 L1.60*W0.80*H0.60mm 0603G-BD-079 Data Sheet View Inventory
SMD LED Disc Blue Clear, IV: 80mcd Min. VF: 2.6V Min. WLD: 468nm Min. 0603BBD0680S01 L1.60*W0.80*H0.60mm 0603B-BD-068 Data Sheet View Inventory
SMD LED Disc Red Clear, IV: 110mcd Min. VF: 1.8V Min. WLD: 620nm Min. 0805RBD0070S01 L2.00*W1.25*H0.80mm 0805R-BD-007 Data Sheet View Inventory
SMD LED Disc Blue Diffused, IV: 118mcd Min. VF: 2.8V Min. WLD: 467nm Min. 0805BBD8100S01 L2.00*W1.25*H0.80mm 0805B-BD-810 Data Sheet View Inventory
SMD LED Dice White Diffused, IV: 170mcd Min. VF: 2.7V Min. CCT: 10000k Min. 0805WBD8120S01 L2.00*W1.25*H0.80mm 0805W-BD-812 Data Sheet View Inventory
SMD LED Dice Yellow-Green Diffused, IV: 53mcd Min. VF: 1.9V Min. WLD: 570nm Min. 0805YGBD008S01 L2.00*W1.25*H0.80mm 0805YG-BD-008 Data Sheet View Inventory

PRODUCTS

Metallized Film Capacitor

SiC Schottky Diode/MOSFET

Super Capacitor (EDLC)

BDBNA000000S00
Description and Main Parameters
Automotive SMD LED PLCC-2 3528 VF:1.9~2.5V. WLD: 612~624nm. IV 710~2290mcd. BDB series Amber Color
Dimension
L3.50*W2.80*H1.85mm
Original Part Number
BDB-NA-000000
PGLLF3053A10B1
Description and Main Parameters
PURE GREEN LED LAMPS with Flange, 3MM Round
Dimension
Φ3.0*5.3mm
Original Part Number
PGLLF3053A10B1
0603BBD0680S01
Description and Main Parameters
SMD LED Disc Blue Clear, IV: 80mcd Min. VF: 2.6V Min. WLD: 468nm Min.
Dimension
L1.60*W0.80*H0.60mm
Original Part Number
0603B-BD-068
0805YGBD008S01
Description and Main Parameters
SMD LED Dice Yellow-Green Diffused, IV: 53mcd Min. VF: 1.9V Min. WLD: 570nm Min.
Dimension
L2.00*W1.25*H0.80mm
Original Part Number
0805YG-BD-008
BDBNR000000S00
Description and Main Parameters
Automotive SMD LED PLCC-2 3528 VF:1.9~2.1V. WLD: 620~628nm. IV 560~1890mcd. BDB series Red Color
Dimension
L3.50*W2.80*H1.85mm
Original Part Number
BDB-NR-000000
YLLLF3053A10B1
Description and Main Parameters
YELLOW LED LAMPS with Flange, 3MM Round
Dimension
Φ3.0*5.3mm
Original Part Number
YLLLF3053A10B1
0603GBD0790S01
Description and Main Parameters
SMD LED Disc Green Clear, IV: 275mcd Min. VF: 2.6V Min. WLD: 520nm Min.
Dimension
L1.60*W0.80*H0.60mm
Original Part Number
0603G-BD-079
0805WBD8120S01
Description and Main Parameters
SMD LED Dice White Diffused, IV: 170mcd Min. VF: 2.7V Min. CCT: 10000k Min.
Dimension
L2.00*W1.25*H0.80mm
Original Part Number
0805W-BD-812
BDBCW2MM000000
Description and Main Parameters
Automotive SMD LED PLCC-2 3528 VF:2.65~3.4V. CCT: 6500~7000K. IV 1170~3600mcd. BDB series Cool White Color
Dimension
L3.50*W2.80*H1.85mm
Original Part Number
BDB-CW2MM-000000
RALLF3053A10B1
Description and Main Parameters
RED LED LAMPS with Flange, 3MM Round
Dimension
Φ3.0*5.3mm
Original Part Number
RALLF3053A10B1
